Amati.linea Streaming Player – get inspiration from invisible, lossless music
Amati.linea = High grade components, High-end engineering attitude, High efficiency
Invisible concept
- Music device embedded to wall boxes, no wires
- DIN rail mountable
- Tiny design 52x90x51 mm
Music sources supported in-box
- DLNA/UPnP server
- Spotify connect (premium only)
- AirPlay
- FTP, NFS, HTTP servers
- SAMBA server
- Internet radio (built-in >6000 radios)
- Built-in 32GB media storage
- Playback from USB storage
BMS ready solution
Audio amplifier
Streaming Player without amplifier
- KNXnet/IP on-board
- Bacnet/IP
High quality sound
- Up to 24 bit 192 kHz
- Lossless audio format (ALAC/FLAC) support
Other features
- 2 x 55W built-in amp (2 speakers)
- 2 x USB on board for Music storage
- Easy operation using iPhone / iPod / iPad app, Android compatible apps
- WEB-based visualization and built-in player
Technical specification
| Feature / Product | Streaming player with 2x55W amplifier, DIN | Streaming player HD without amplifier, DIN |
|---|---|---|
| Connectivity | 1 x 100BaseTX ethernet 2 x USB, 1 x IR input, 3.5 mm 1 x 2 outputs for stereo loudspeakers, clamp 1 x Analog subwoofer output 1 x 0-10V analog input for external volume control, clamp 4 x Binary inputs, for standard push-button connection |
1 x 100BaseTX ethernet 1 x USB, 2 x line-out, screw/RCA 1 x 0-10V analog input, clamp 4 x triggers for zone control, clamp |
| Audio amplifier | Continues output power: 2 x 55W THD+N: 0.07% SNR: 102dB |
– |
| Sampling frequencies / resolutions | 8kHz to 384kHz | 8kHz to 384kHz / 16, 24, 32 bit |
| Supported audio formats | MP3, WAV, AAC, WMA, FLAC, lossless FLAC 96/24, 24/192 |
MP3, WAV, AAC, WMA, FLAC, lossless FLAC 96/24 |
| Protocols supported | DLNA, UPnP, AirPlay, FTP, NFS, HTTP, KNXnet/IP, SAMBA | DLNA, UPnP, AirPlay, FTP, NFS, HTTP, KNXnet/IP, SAMBA |
| Clock Oscillator | Low jitter (0.5 psec typ.) | Low jitter (0.5 psec typ.) |
| Power supply supported | 18-26 VDC | 7-36 VDC |
| Power consumption | 1.2W idle mode | 1.2W idle mode |
| Weight | 0.3 kg | 0.3 kg |
| Dimensions/Enclosure | 70 x 90 x 51 mm (W x H x D), DIN-rail plastic case | 52 x 90 x 51 mm (W x H x D), DIN-rail plastic case |
| Operating temperature | -5ºC to 55ºC | -5ºC to 55ºC |
You can download our information materials as PDF files here.
Download Streaming Player with Amplifier Datasheet
Download Streaming Player without Amplifier Datasheet
Quick settings
Audio control function mapping to KNX group-addresses
Map specific song from media sources or Internet radio to KNX group-address, Sound notification system
Built-in player – quick control
Built-in internet radios
Playlists
Mapped file systems
Stream directly from iTunes via Airplay
Control from touch devices
Control from touch devices
